Load Cell

"Ideal for industrial and research use"

PRODUCTS

Load Cell

1

CBMS

Miniature

Compression
Sub-Miniature Load Cell (3kg ~ 30kg)
0.7~1.5mV/V, IP60


2

CBFS

Compression
Miniature Load Cell (3kg ~ 1t)
1mV/V, IP65


3

CWFS

Center Hole Type
Miniature Load Cell (20kg ~ 200kg)
Stainless Steel
2mV/V, IP64


4

CDFS

Compression & Tension
Miniature Load Cell (10kg ~ 200kg)
Stainless Steel
1mV/V, IP67


5

CBL

Compression
Miniature Load Cell (200kg ~ 3t)
Stainless Steel
2mV/V, IP68


6

CML

Compression
Miniature Load Cell (5t ~ 15t)
Stainless Steel
2mV/V, IP65


7

DBSM

Compression & Tension
Built-in overload protection
(3kg ~ 30kg)
2mV/V, IP64


8

DBCM

Compression & Tension
Miniature Load Cell (2kg ~ 300kg)
2mV/V, IP64


9

BMK

Weigh Module

Specially designed for hopper,
bin and tank
(100kg ~ 5t)


10

BMA

Weigh Module

Specially designed for hopper,
bin and tank
(20kg ~ 300kg)


11

BMDX

Weigh Module

Specially designed for hopper,
bin and tank
(1t ~ 3t)


12

BMLX

Weigh Module

Specially designed for hopper,
bin and tank
(2t ~ 15t)


13

BMH

Weigh Module

Specially designed for hopper and tank
(1t ~ 10t)


14

CDBM

Weigh Module

Compression Load Cell (5t ~ 15t)
Nickel Plated Alloy Steel
2mV/V, IP67


15

BMD

Weigh Module

Specially designed for hopper and tank
(5t ~ 15t)


16

CDUP

Weigh Module

Compression Load Cell (15t ~ 25t)
Alloy Tool Steel
2mV/V, IP67


17

CLWXE

Flameproof Type

Compression Load Cell (2t ~ 15t)
Stainless Steel & Welded Cover
2mV/V, IP68


18

OBBL

Bending Beam Load Cell (20kg ~ 200kg)
Aluminum
2mV/V, IP65


19

OSBH

Shear Beam Load Cell (200kg ~ 10t)
Nickel Plated Alloy Steel
3mV/V, IP67


20

OSBK

Shear Beam Load Cell (100kg ~ 10t)
Nickel Plated Alloy Steel
3mV/V, IP67


21

OSW

Shear Beam Load Cell (500kg ~ 5t)
Stainless Steel & Welded Cover
2mV/V, IP68


22

OSKW

Shear Beam Load Cell (500kg ~ 5t)
Stainless Steel & Welded Cover
2mV/V, IP68


23

OSBHG / OSWG

Shear Beam Load Cell (200kg ~ 2t)
Alloy Tool Steel or Stainless Steel
3mV/V or 2mV/V, IP67 / IP68



24

OS76

Compression Load Cell
(500kg ~ 2t)
Nickel Plated Alloy Steel
2mV/V, IP67


25

OBBA

Bending Beam Load Cell (10kg ~ 300kg)
Stainless Steel
2mV/V, IP68


26

OBBN

Bending Beam Load Cell (20kg ~ 300kg)
Stainless Steel
2mV/V, IP68



27

OBBS

Bending Beam Load Cell (20kg ~ 500kg)
Stainless Steel
2mV/V, IP68


28

DBBP

S-Beam Load Cell (20kg ~ 5t)
Nickel Plated Alloy Steel
3mV/V, IP67


29

DBCR

S-Beam Load Cell (100kg ~ 5t)
Nickel Plated Alloy Steel
2mV/V, IP67


30

DBWR

S-Beam Load Cell (500kg ~ 5t)
Stainless Steel & Welded Cover
2mV/V, IP68


31

CWL

Center hole type Load Cell
(500kg ~ 5t)
Stainless Steel
2mV/V, IP68


32

CDES

Compression & Tension
Low Profile Load Cell (50kg ~ 2t)
Stainless Steel & Welded Cover
2mV/V, IP68


33

CBESA

Compression
Low Profile Load Cell (50kg ~ 20t)
2mV/V, IP68


34

DSCS

Compression & Tension
Low Profile Load Cell (200kg ~ 1t)
Stainless Steel
3mV/V, IP68


35

CMCS

Compression
Low Profile Load Cell (500kg ~ 10t)
Stainless Steel & Welded Cover
2mV/V, IP68


36

DSCK

Compression & Tension
Low Profile Load Cell (1t ~ 20t)
Alloy Tool Steel
3mV/V, IP67


37

DSCH / DSCHS

Compression & Tension
Low Profile Load Cell (1t ~ 100t)
Alloy Tool Steel or Stainless Steel
3mV/V, IP67 / IP68


38

CSCK

Compression Load Cell (10t ~ 100t)
Alloy Tool Steel
3mV/V, IP67


39

CSDH

Compression Load Cell (30t ~ 100t)
Alloy Tool Steel
3mV/V, IP67


40

OBUG

Single point Miniature Load Cell
(1kg ~ 3kg)
Aluminum
1mV/V, IP65


41

OBUH / OBUHS

Single point Load Cell (5kg ~ 100kg)
Aluminum, Stainless Steel
2mV/V, IP65



42

OBU

Single point Load Cell (1kg ~ 250kg)
Aluminum
2mV/V, IP65


43

OBUX

Single Point Load Cell (50kg ~ 500kg)
Aluminum
2mV/V, IP67


44

TR

Tension Load Cell (50kg ~ 10t)
Alloy Tool Steel
3mV/V, IP67


45

CR

Compression Load Cell (200kg ~ 20t)
Alloy Tool Steel
3mV/V, IP67


46

CCDM / CCCM

Compression Load Cell (10t ~ 300t)
Alloy Tool Steel
1.5 mV/V, IP67


47

CCDH / CCDHS

Compression Load Cell (10t ~ 500t)
Alloy Tool Steel or Stainless Steel
1.5mV/V, IP67 / IP68


48

BCCU

Compression Load Cell (10t ~ 50t)
Alloy Tool Steel
1.5 mV/V, IP67


49

DBXE

Flameproof Type

Compression & Tension Load Cell
(1t ~ 3t)
1.5mV/V, IP68


50

OSWXE

Flameproof Type

Shear Beam Load Cell (500kg ~ 5t)
Stainless Steel
2mV/V, IP67


51

OBBXE

Flameproof Type

Bending Beam Load Cell (10kg ~ 300kg)
Stainless Steel
2mV/V, IP67


52

CCHXE

Flameproof Type

Compression Load Cell (10t ~ 50t)
Stainless Steel
2mV/V, IP67


53

BTA

Pillow Block Type,
Horizontal Measurement (5kN ~ 50kN)
Nickel Plated Alloy Steel
1mV/V, IP67


54

BTV

Pillow Block Type,
Vertical Measurement (50kN ~ 100kN)
Nickel Plated Alloy Steel
1mV/V, IP67


55

CDBH

Double Ended Shear Beam Load Cell
(5t ~ 15t)
Nickel Plated Alloy Steel
3mV/V, IP67


56

CS61

Center Hole Type
Low Profile Load Cell (1t ~ 3t)
Nickel Plated Alloy Steel
1.5mV/V, IP67


57

BCH

Compression Load Cell (1t ~ 50t)
Nickel Plated Alloy Steel
1mV/V, IP64


58

CWFK

Compression
Center Hole Type Load Cell (10t ~ 200t)
Alloy Tool Steel
1mV/V, IP67


59

CSDKA

Pin Type Load Cell (2t ~ 50t)
Nickel Plated Alloy Steel
1.5mV/V, IP67


60

PSA

Slim Platform Scale (29mm)
(50kg ~ 300kg)
Stainless Steel Cover


61

CDKM

Pin Type Load Cell (5t ~ 60t)
Stainless Steel
1mV/V, IP68


62

BXY

X-Y Force Sensor (250kgf ~ 1tf)
Stainless Steel
2mV/V, IP54


63

WLFN2

Measuring The Tension of Wire Ropes
(0.5t ~ 10t per Rope)
Nickel Plated Alloy Steel
1mV/V, IP64


64

TLC

Tension Load Cell (500kg ~ 5t)
Nickel Plated Alloy Steel
1.5mV/V, IP67


65

TLH

Tension Load Cell (10t ~ 50t)
Nickel Plated Alloy Steel
1mV/V, IP67


66

Customized
Pin Type Load Cell

500kg ~ 200t
Alloy Steel or Stainless Steel


67

Customized
Weighing Platform

50kg ~ 2t
Stainless Steel Cover
